HOT WiFi IR NVG ONVIF P2P Pan/Tilt HD Home phone Security Network IP Camera

Feature	Features	Small body size,perfect combination of hardware and software through software limit, and more stable.
System	OS	Embedded Linux OS
	system security	Three level user authority management
	online users	support 4 online visitors simultaneously
	DDNS	Free DDNS
	Control protocol	ONVIF 2.0 protocol, high interoperability
	Processor	Hisilicon processor,built-in ARM926 @Max. 440MHz and a high-speed video co-processor.
	Reset	Long press for 15 seconds to restore back to factory settings
Collection	Image sensor	1/4inch 720p Progressive scan CMOS sensor
	CMOS	support AWB, AGC, BLC
	sensor size	3.84mm×2.16mm
	SNR	≥39dB
	Minimum illumination	0.8Lux/F1.４（colourful model ）,0.3Lux/F1.（B&W mode）
	Lens/viewing angle	3.6mm@F1.４/56.14˚
	Night vision	Dual IR-CUT filter auto switch, 9pcs 850nmΦ5mmLED,10mIR distance
	IR control	IR turned on: night vision view enabled, infrared Ray, ICR auto detect. IR turned off: night vision disabled, infrared ray off, ICR stay in day view mode.
Video	Compression Format	H.264 Main Profile/H.264 Baseline Profile/MJPEG/JPEG Baseline
	Video coding process	Multi-stream：720P/24fps+VGA/30fps+QVGA/30fps+720P @1fsJPEG snapshot
	Resolution	720p/VGA/QVGA
	Bit Rate	CBR/VBR, output bit rate range：128～4096kbps
	Frame rate	25fps
	Picture Adjustment	Contrast, brightness, saturation, chroma are adjustable.
Audio	Input	Built in -48dB Microphone
	Output	Built in speaker(8Ω1W)
	Sampling frequency / width	8KHz/16bit
	Compression format	ADPCM/32kbps
Network	Interface	10Base-T / 100Base-TX, RJ45 connector
	Network Protocol	TCP/IP,HTTP,TCP,UDP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPnP,RTSP,P2P,ONVIFetc.
	WIFI	WiFi802.11b/g/n
	Antenna	3dBi antenna，stronger signal, more stable
	Wireless network security	one key setup WiFi, do not need network cable .
storage	Storage mode	Local storage / client storage
	card	support 64GTF card .
	Interface	MicroSD
Pan-Tilt	P/T	Pan:270°,Tilt:70°
	Preset Postion	support up to 15 preset postions
	Limit method	Software limit position, more accurate preset positions,lower Pan Tilt failure rate
Alarm	Motion detection	Support motion detection
Alarm	Alarm action	Image upload via email/FTP server
Physical index	Rated Voltage	DC5/2A±0.3V
	Power comsumption	Rated power：3.0Ｗ(IR ON)
	Working environment	Working Temperature：-20～70℃，Working Humidity 90%
	Weight	Gross Weight ：295g（Note: in kind prevail）
	Housing material	ABS plastics
	Camera size	98x105x120mm(L×W×H)
	Installation	Wall mounting, ceiling mounting
