Features
High-sensitivity 1/4" CMOS sensor (300,000 pixels)
Optimized MJPEG video compression for transmission
Auto IR-LED illumination for night vision (up to 15 meters)
Waterproof for outdoor use
High image & video quality
Wi-Fi compliant with wireless standards IEEE 802.11b/g
Support smart mobile surveillance via iPhone, Android, Windows Mobile, Java, etc
Supports IE/Firefox/Google browser or any other standard browsers
Supports remote viewing & record from anywhere anytime
Support motion detection alert via email or upload image to a specified FTP server
Support image full screen and image snapshot
Multi-level users management and passwords definition
Multi-Protocol support and Transportation (such as TCP/IP, SMTP, HTTP and etc)
Support both WEP & WPA WPA2 Encryption
Friendly IP Camera Setup Wizard, friendly Graphical User Interface, DIY installation
Multi-Language Support Built-In Web Interface: English, Deutsch, French, Italian, Japanese, Korean and Chinese
Video/Snapshot Storage on Local Hard Drives
Specification
|
Model
|
IP602W
|
|
Image Sensor
|
Image Sensor
|
1/4 Inch Color CMOS Sensor
|
|
Display Resolution
|
640 x 480 Pixels(300K Pixels)
|
|
Lens
|
f=6mm
|
|
Minimum Illumination
|
0.1 Lux
|
|
Lens
|
Lens Type
|
Glass Lens
|
|
Viewing Angle
|
Horizontal:28.5° / Vertical:21.5°
|
|
Audio
|
Audio Compression
|
ADPCM
|
|
Video
|
Image Compression
|
MJPEG
|
|
Image Frame Rate
|
25fps (Max.)
|
|
Image Resolution
|
640 x 480(VGA), 320 x 240(QVGA),
|
|
User Authentication
|
Authentication: User name/password;
|
|
Users Group
|
Administrator/Operator/Guest
|
|
Simultaneous Viewers
|
10 viewers(320x240) & 4 viewers(640x480)
|
|
Mobile View
|
Supports smart phones with Iphone/Android/ Java and other smart mobile phones
|
|
Night visibility
|
Φ5mm, 30 IR LED lights, Wireless night visibility up to 15 meters
|
|
Light Frequency
|
50Hz, 60Hz or Outdoor
|
|
Video Parameters
|
Brightness, Contrast
|
|
Network
|
Ethernet Port
|
RJ-45 (10 BASE-T/ 100 BASE-TX)
|
|
Supported Protocols
|
TCP/ UDP/ IP/ ARP/ ICMP/ DHCP/ DNS/ HTTP/FTP/ SMTP/ NTP/ PPPOE/ UPNP/ DDNS
|
|
Wireless Standard
|
IEEE 802.11b/g
|
|
Wireless Security
|
WEP/ WPA/ WPA2 Encryption
|
|
Alarm
|
Motion Detection
|
Support motion detection and image snapshot
|
|
Alarm Events
|
• Notification via email, FTP
• Video recording to local storage
|
|
Physical Property
|
Color
|
Silver
|
|
Package Dimension
|
245(L)*115(W)*185(H)mm
|
|
Gross Weight
|
1150g (box included)
|
|
Power
|
Power Supply
|
DC 12V/1A (EU, US, AU,UK adapter or other types optional)
|
|
Power Consumption
|
4 Watts (Infrared off )/ 6 Watts (Infrared on)
|
|
Operating Environment
|
Operating Tempt.
|
-10° ~ 55°C (14°F ~ 131°F)
|
|
Operating Humidity
|
20% ~ 80% RH (non-condensing)
|
|
Storage Tempt.
|
-20°C ~ 60° (-4°F ~ 140°F)
|
|
Storage Humidity
|
20% ~ 95% RH (non-condensing)
|
|
PC Configuration
|
CPU
|
2.0GHZ or above (suggested 3.0GHz)
|
|
Memory
|
256MB or above (suggested 1.0GHz)
|
|
Graphics Card
|
64M or above
|
|
Supported OS
|
Microsoft Windows 2000/XP/Vista/ MAC OS
|
|
Supported Browsers
|
IE 6.0 or above version, Firefox, Safari, Opera, Chrome or others
|
|
Certification
|
CE, FCC, RoHS
|
|
Warranty
|
One year Warranty
|
Package Includes
1 X Wireless IP Camera IP602W
1 X Power adapter for Camera
1 X Wi-Fi Antenna
1 X User Manual
1 X CD (driver and tool)
1 X Mounting bracket
Some Screws
