Features
|
802.11ac, 2.4GHZ/5.0GHz dual band, transfer speed up to 1167 Mbps Real 2X2 dual band antennas wall penetrate mode supported Mini become home entertainment center with exrternal sroranf deciece Born to pair with Mi TV, Mi phone, Mi Pad, no more cables for data transfer between family members and smart devices, each screen can play movie and photo with Xiaomi mini router Standards: Wi-Fi 802.11g, Wi-Fi 802.11b, Wi-Fi 802.11n, Wi-Fi 802.11ac(Next Generation of Wi-Fi); Support Firewall VPN USB Storage, Dual mode, 2.4G and 5G, up to 1167Mbps througput Wireless router speed up to 300Mbps ideal applications for video streaming, online gaming VoIP, web browsing and multi- tasking Based on OpenWRT Smart System,intelligent routing App, equipment and documents are easily to manage
|
General Specs
|
Brand
|
Xiaomi
|
Material
|
ABS+PC
|
WIFI Speed
|
2.4GHz 300Mbps+5GHz 867Mbps
|
RAM
|
128MB DDR2
|
ROM
|
16MB SPI Flash
|
Wireless Channel
|
2.4GHz Channel: 1,2,3,4,5,6,7,8,9,10,11,12,13 5GHz Channel: 149,153,157,161,165 5GHz DFS Channel:36,40,44,48,52,56,60,64
|
Modulation Mode
|
11b:DSSS:DBPSK(1Mbps),DQPSK(2Mbps), CCK(5.5/11Mbps) 11a/g:OFDM:BPSK(6/9Mbps), QPSK(12/18Mbps),16QAM(24/36Mbps), Q64QAM(48/54Mbps) 11n:MIMO-OFDM:BPSK,QPSK,16QAM,64QAM. Q Rate:MCS0~MCS15 11ac:MIMO-OFDM:BPSK, QQPSK,16QAM,64QAM,256QAM. Q Rate:MCS0~MCS9
|
Receiving Sensitivity
|
11Mbps:≤-90dBm,54 Mbps:≤-72dBm, HT20 QMCS7:≤-69dBm, QHT40 MCS7:≤-66dBm, VHT20 MCS8:≤-65dBm, Q VHT40 MCS9:≤-60dBm, QVHT80 MCS9:≤-58 dBm
|
Operating System
|
MiWiFi ROM (based on OpenWRT)
|
Protocol Standards
|
IEEE 802.11a/b/g/n/ac,IEEE 802.3/3u
|
Certification Standards
|
GB9254-2008 YD/T993-1998 GB4943.1-2011
|
Working Temperature
|
0-40℃
|
Working Humidity
|
10%-90%RH
|
Storage Temperature
|
-40-70℃
|
Storage Humidity
|
5%-90%RH
|
Dimension
|
150 x 137 x 30 mm
|
Weight
|
251 g
|
Package Details
Weight: 299.60 g
Size: 20*17*5 cm
